系统环境

[root@node01 ~]# cat /etc/redhat-release
CentOS Linux release 7.2.1511 (Core)
[root@node01 ~]# uname -r
3.10.0-327.el7.x86_64
[root@node01 ~]# getenforce
Disabled

更新yum源

##更新Base源
~]# wget -O /etc/yum.repos.d/CentOS-Base.repo http://mirrors.aliyun.com/repo/Centos-7.repo
##更新epel源
~]# wget -O /etc/yum.repos.d/epel.repo http://mirrors.aliyun.com/repo/epel-7.repo

安装软件包

[root@node01 ~]# yum -y install openvpn easy-rsa

看这里，如果是 2.2 的可以参考另一篇文字https://www.xionghaier.cn/?p=337

配置 easy-rsa-3.0

复制文件

[root@node01 ~]# cp -r /usr/share/easy-rsa/ /etc/openvpn/easy-rsa
[root@node01 ~]# cd /etc/openvpn/easy-rsa/
[root@node01 easy-rsa]# \rm 3 3.0            #删除软连接目录
[root@node01 easy-rsa]# cd 3.0.3/
[root@node01 3.0.3]# find / -type f -name "vars.example"|xargs cp -t . && mv vars.example vars
[root@node01 3.0.3]# ls
easyrsa openssl-1.0.cnf vars x509-types
[root@node01 3.0.3]# tree .
.
├── easyrsa
├── openssl-1.0.cnf
├── vars
└── x509-types
 ├── ca
 ├── client
 ├── COMMON
 ├── san
 └── server

1 directory, 8 files

生成证书

创建一个新的 PKI 和 CA证书

[root@node01 3.0.3]# ./easyrsa init-pki    ###创建空的pki

Note: using Easy-RSA configuration from: ./vars

init-pki complete; you may now create a CA or requests.
Your newly created PKI dir is: /etc/openvpn/easy-rsa/3.0.3/pki


[root@node01 3.0.3]# ./easyrsa build-ca nopass ###创建新的CA，不使用密码

Note: using Easy-RSA configuration from: ./vars
Generating a 2048 bit RSA private key
...+++
....................+++
writing new private key to '/etc/openvpn/easy-rsa/3.0.3/pki/private/ca.key.jLD7qrTaCY'
-----
You are about to be asked to enter information that will be incorporated
into your certificate request.
What you are about to enter is what is called a Distinguished Name or a DN.
There are quite a few fields but you can leave some blank
For some fields there will be a default value,
If you enter '.', the field will be left blank.
-----
Common Name (eg: your user, host, or server name) [Easy-RSA CA]:回车

CA creation complete and you may now import and sign cert requests.
Your new CA certificate file for publishing is at:
/etc/openvpn/easy-rsa/3.0.3/pki/ca.crt

创建服务端证书

[root@node01 3.0.3]# ./easyrsa gen-req server nopass

Note: using Easy-RSA configuration from: ./vars
Generating a 2048 bit RSA private key
.......................+++
...........+++
writing new private key to '/etc/openvpn/easy-rsa/3.0.3/pki/private/server.key.CB0dYz0h8K'
-----
You are about to be asked to enter information that will be incorporated
into your certificate request.
What you are about to enter is what is called a Distinguished Name or a DN.
There are quite a few fields but you can leave some blank
For some fields there will be a default value,
If you enter '.', the field will be left blank.
-----
Common Name (eg: your user, host, or server name) [server]:

Keypair and certificate request completed. Your files are:
req: /etc/openvpn/easy-rsa/3.0.3/pki/reqs/server.req
key: /etc/openvpn/easy-rsa/3.0.3/pki/private/server.key

签约服务端证书

[root@node01 3.0.3]# ./easyrsa sign server server

Note: using Easy-RSA configuration from: ./vars


You are about to sign the following certificate.
Please check over the details shown below for accuracy. Note that this request
has not been cryptographically verified. Please be sure it came from a trusted
source or that you have verified the request checksum with the sender.

Request subject, to be signed as a server certificate for 3650 days:

subject=
 commonName = server

Type the word 'yes' to continue, or any other input to abort.
 Confirm request details: yes
Using configuration from ./openssl-1.0.cnf
Check that the request matches the signature
Signature ok
The Subject's Distinguished Name is as follows
commonName :ASN.1 12:'server'
Certificate is to be certified until May 8 01:59:11 2028 GMT (3650 days)

Write out database with 1 new entries
Data Base Updated

Certificate created at: /etc/openvpn/easy-rsa/3.0.3/pki/issued/server.crt

生成DH验证文件Diffie-Hellman

[root@node01 3.0.3]# ./easyrsa gen-dh

##注生成diffie hellman参数用于增强openvpn安全性生成需要漫长等待时间
Note: using Easy-RSA configuration from: ./vars
Generating DH parameters, 2048 bit long safe prime, generator 2
This is going to take a long time
...................................+...................................................+.......................
.....................................................................................................+..+......
.+..............................................................................................+..............
.............................+...++*++*

DH parameters of size 2048 created at /etc/openvpn/easy-rsa/3.0.3/pki/dh.pem

到这里服务端的证书就创建完了，然后创建客户端的证书。

创建客户端证书

复制文件

[root@node01 ~]# cp -r /usr/share/easy-rsa/ /etc/openvpn/client/easy-rsa
[root@node01 ~]# cd /etc/openvpn/client/easy-rsa/
[root@node01 easy-rsa]# \rm 3 3.0
[root@node01 easy-rsa]# cd 3.0.3/
[root@node01 3.0.3]# find / -type f -name "vars.example" | xargs -i cp {} . && mv vars.example vars
[root@node01 3.0.3]# tree .
.
├── easyrsa
├── openssl-1.0.cnf
├── vars
└── x509-types
 ├── ca
 ├── client
 ├── COMMON
 ├── san
 └── server

1 directory, 8 files

生成证书

[root@node01 3.0.3]# pwd
/etc/openvpn/client/easy-rsa/3.0.3
[root@node01 3.0.3]# ./easyrsa init-pki #创建新的pki

Note: using Easy-RSA configuration from: ./vars

init-pki complete; you may now create a CA or requests.
Your newly created PKI dir is: /etc/openvpn/client/easy-rsa/3.0.3/pki

[root@node01 3.0.3]# ./easyrsa gen-req wangmazi nopass    #客户证书名为王麻子，没有密码

Note: using Easy-RSA configuration from: ./vars
Generating a 2048 bit RSA private key
......................+++
........................+++
writing new private key to '/etc/openvpn/client/easy-rsa/3.0.3/pki/private/wangmazi.key.msHOTrO0vN'
-----
You are about to be asked to enter information that will be incorporated
into your certificate request.
What you are about to enter is what is called a Distinguished Name or a DN.
There are quite a few fields but you can leave some blank
For some fields there will be a default value,
If you enter '.', the field will be left blank.
-----
Common Name (eg: your user, host, or server name) [wangmazi]:回车

Keypair and certificate request completed. Your files are:
req: /etc/openvpn/client/easy-rsa/3.0.3/pki/reqs/wangmazi.req
key: /etc/openvpn/client/easy-rsa/3.0.3/pki/private/wangmazi.key

最后签约客户端证书

[root@node01 3.0.3]# cd /etc/openvpn/easy-rsa/3.0.3/
[root@node01 3.0.3]# pwd
/etc/openvpn/easy-rsa/3.0.3
[root@node01 3.0.3]# ./easyrsa import-req /etc/openvpn/client/easy-rsa/3.0.3/pki/reqs/wangmazi.req wangmazi

Note: using Easy-RSA configuration from: ./vars

The request has been successfully imported with a short name of: wangmazi
You may now use this name to perform signing operations on this request.
大致意思为：
该请求已成功导入，名称为：王麻子
现在可以使用此名称来执行此请求的签名操作。

[root@node01 3.0.3]# ./easyrsa sign client wangmazi

Note: using Easy-RSA configuration from: ./vars


You are about to sign the following certificate.
Please check over the details shown below for accuracy. Note that this request
has not been cryptographically verified. Please be sure it came from a trusted
source or that you have verified the request checksum with the sender.

Request subject, to be signed as a client certificate for 3650 days:

subject=
 commonName = wangmazi


Type the word 'yes' to continue, or any other input to abort.
 Confirm request details: yes
Using configuration from ./openssl-1.0.cnf
Check that the request matches the signature
Signature ok
The Subject's Distinguished Name is as follows
commonName :ASN.1 12:'wangmazi'
Certificate is to be certified until May 8 02:44:40 2028 GMT (3650 days)

Write out database with 1 new entries
Data Base Updated

Certificate created at: /etc/openvpn/easy-rsa/3.0.3/pki/issued/wangmazi.crt

整理证书

服务端所需要的文件

[root@node01 3.0.3]# mkdir /etc/openvpn/certs
[root@node01 3.0.3]# cd /etc/openvpn/certs
[root@node01 certs]# cp /etc/openvpn/easy-rsa/3.0.3/pki/dh.pem .
[root@node01 certs]# cp /etc/openvpn/easy-rsa/3.0.3/pki/ca.crt .
[root@node01 certs]# cp /etc/openvpn/easy-rsa/3.0.3/pki/issued/server.crt .
[root@node01 certs]# cp /etc/openvpn/easy-rsa/3.0.3/pki/private/server.key .
[root@node01 certs]# ll
total 20
-rw------- 1 root root 1172 May 11 11:55 ca.crt
-rw------- 1 root root 424 May 11 11:55 dh.pem
-rw------- 1 root root 4547 May 11 11:55 server.crt
-rw------- 1 root root 1704 May 11 11:55 server.key

客户端所需的文件

[root@node01 certs]# mkdir /etc/openvpn/client/wangmazi/
[root@node01 certs]# cd /etc/openvpn/client/wangmazi/
[root@node01 wangmazi]# cp /etc/openvpn/easy-rsa/3.0.3/pki/ca.crt .
[root@node01 wangmazi]# cp /etc/openvpn/easy-rsa/3.0.3/pki/issued/wangmazi.crt .
[root@node01 wangmazi]# cp /etc/openvpn/client/easy-rsa/3.0.3/pki/private/wangmazi.key .
[root@node01 wangmazi]# ll
total 16
-rw------- 1 root root 1172 May 11 11:57 ca.crt
-rw------- 1 root root 4438 May 11 11:58 wangmazi.crt
-rw------- 1 root root 1704 May 11 11:58 wangmazi.key

说明：再次添加其他用户从生成客户端证书./easyrsa gen-req开始就可了

服务器配置文件

[root@node01 ~]# vim /etc/openvpn/server.conf
local 118.190.201.68
port 1194
proto tcp
dev tun

ca /etc/openvpn/certs/ca.crt
cert /etc/openvpn/certs/server.crt
key /etc/openvpn/certs/server.key
dh /etc/openvpn/certs/dh.pem

ifconfig-pool-persist /etc/openvpn/ipp.txt

server 10.8.0.0 255.255.255.0
push "route 172.16.1.0 255.255.255.0"
push "redirect-gateway def1 bypass-dhcp"
push "dhcp-option DNS 223.5.5.5"
push "dhcp-option DNS 223.6.6.6"
client-to-client

keepalive 20 120
comp-lzo
#duplicate-cn

user openvpn
group openvpn

persist-key
persist-tun
status openvpn-status.log
log-append openvpn.log
verb 1
mute 20

启动服务

启动服务

[root@node01 ~]# systemctl start openvpn@server
[root@node01 ~]# lsof -i:1194
COMMAND      PID        USER       FD    TYPE     DEVICE     SIZE/OFF    NODE    NAME
openvpn      16113      openvpn    6u    IPv4     84651       0t0        TCP     118.190.201.68:openvpn (LISTEN)

配置iptables及转发

关闭防火墙

[root@node01 ~]# systemctl stop firewalld.service //停止服务
[root@node01 ~]# systemctl disable firewalld.service //禁止开启动
[root@node01 ~]# firewall-cmd --state //查看状态

安装iptables，写入策略，开启1194及22端口

22端口已默认开启

[root@node01 ~]# yum -y install iptables iptables-services
[root@node01 ~]# iptables -A INPUT -p udp -m state --state NEW -m udp --dport 1194 -j ACCEPT
[root@node01 ~]# iptables-save
# Generated by iptables-save v1.4.21 on Fri May 11 12:24:24 2018
*filter
:INPUT ACCEPT [20:1560]
:FORWARD ACCEPT [0:0]
:OUTPUT ACCEPT [11:1192]
-A INPUT -p udp -m state --state NEW -m udp --dport 1194 -j ACCEPT
COMMIT
# Completed on Fri May 11 12:24:24 2018
###重启iptables并添加规则
[root@node01 ~]# systemctl restart iptables.service
[root@node01 ~]# iptables -t nat -A POSTROUTING -s 10.8.0.0/24 -o eth0 -j MASQUERADE   #NAT规则

开启内核转发

[root@node01 ~]# echo "net.ipv4.ip_forward = 1" >> /etc/sysctl.conf
[root@node01 ~]# sysctl -p
net.ipv4.ip_forward = 1

编辑client.ovpn文件

[root@node01 openvpn]# vim client.ovpn
client
proto udp
dev tun
remote 118.0.0.0 1194

ca ca.crt
cert client.crt
key client.key

resolv-retry infinite
nobind
mute-replay-warnings

keepalive 20 120
comp-lzo
user openvpn
group openvpn

persist-key
persist-tun
status openvpn-status.log
log-append openvpn.log
verb 3
mute 20

./easyrsa命令小结

创建一个新的PKI和CA

 ./easyrsa init-pki
 ./easyrsa build-ca

签约客户端证书

./easyrsa gen-req EntityName ./easyrsa import-req /tmp/path/to/import.req EntityName ##将请求（.req文件）传输到CA系统并导入它。这里给出的名称是任意的，只用于命名请求文件。

将请求标记为正确的类型。这个例子使用一个客户端类型

 ./easyrsa sign-req client EntityName

撤销证书并创建CRL

这是特定于CA的任务。

要永久吊销已颁发的证书，请提供导入期间使用的简称：

 ./easyrsa revoke EntityName

要创建一个更新的CRL，其中包含到目前为止所有已撤销的证书

./easyrsa gen-crl

DH params可以通过以下方式生成

 ./easyrsa gen-dh ##生成Diffie-Hellman（DH）参数

显示请求或证书的详细信息

./easyrsa show-req EntityName
./easyrsa show-cert EntityName

更改私钥密码短语
RSA和EC私钥可以重新加密，因此根据密钥类型，可以使用以下命令之一提供新的密码短语

./easyrsa set-rsa-pass EntityName
./easyrsa set-ec-pass EntityName

或者，可以使用’nopass‘标志完全删除密码。详情请查阅命令帮助。

测试

参考https://www.xionghaier.cn/?p=337
